TL;DR
China is making significant progress in domestic chip manufacturing by focusing on practical, iterative process learning rather than just acquiring advanced machinery. This approach is crucial for achieving scalable, reliable production of cutting-edge chips, influencing global tech dynamics.
China is actively manufacturing domestic immersion DUV lithography machines and developing EUV prototypes, marking tangible progress in its semiconductor industry. This shift is driven by a focus on practical process mastery rather than merely acquiring advanced equipment, a strategy that is central to overcoming the complex challenges of chip manufacturing.
Multiple credible sources confirm that China has begun mass-producing domestically-made immersion DUV lithography machines capable of 28-nanometer production, with some capabilities reaching 7-nanometer and potentially 5-nanometer nodes through multi-patterning. These systems are largely sourced from domestic components, and a prototype EUV machine is also reported to be in development, signaling China’s ambition to advance in cutting-edge lithography technology.
However, the journey from producing a machine to achieving reliable, high-yield, commercial-scale manufacturing remains complex. Current yields for 5-nanometer chips in China are estimated at around 20 percent, far below the 90 percent yields typical of leading global fabs using EUV. Additionally, China remains dependent on imported high-purity materials, such as photoresist from Japan, and its domestic tools are estimated to lag behind the most advanced Western counterparts by about four generations. The installed base of equipment also relies heavily on Western servicing, creating a dependency that hampers full self-sufficiency.
Every few weeks a headline says China cracked the last hard problem in chipmaking — and triggers alarm in one camp, triumph in the other. Both overreact, because both mistake a learning-by-doing problem for a copying problem. It isn’t one.
▲ Forward-looking · figures are point-in-time estimates“A machine exists” and “a machine makes advanced chips at scale, profitably, for years” are separated by a chasm — made of things that only accumulate with time.
In a race, a burst of speed closes the gap. In a phase transition, you can’t move faster to cross over — you have to accumulate enough, slowly, until the system changes state.
When you see “China achieves X,” ask which of two very different claims is actually being made.
Even amid the loud headlines, the quiet data points all say the same thing.
No prototype, no shipped tool, no yield headline teleports past it.
Understanding the True Barriers to China’s Chip Industry Advancement
This progress signifies a strategic shift in China’s technology development, emphasizing the importance of learning-by-doing—the iterative process of gaining tacit knowledge through repeated practice. Achieving reliable, high-yield manufacturing at advanced nodes depends not just on acquiring machines but on accumulating years of process experience, fixing failures, and developing expertise. This approach influences global supply chains, technological sovereignty, and the pace of innovation in the semiconductor industry.
The Semiconductor Manufacturing Business: A Comprehensive Guide
As an affiliate, we earn on qualifying purchases.
As an affiliate, we earn on qualifying purchases.
China’s Semiconductor Ambitions and Past Challenges
Over the past decade, China has sought to reduce reliance on Western chipmaking tools through a combination of government backing and industry investment. Despite significant progress, the industry has faced persistent challenges in mastering the complex, tacit knowledge required for advanced manufacturing. Recent developments, including domestic production of DUV lithography machines and prototypes of EUV systems, mark a critical phase in this ongoing effort, moving from demonstration to commercial viability.
"The real challenge is not just building the machines but mastering the process through years of iterative learning, which cannot be rushed or bought."
— Thorsten Meyer
As an affiliate, we earn on qualifying purchases.
What Aspects of China’s Semiconductor Progress Remain Unclear
It is still unclear when China will achieve consistent, high-yield production at sub-10 nanometer nodes on a commercial scale. The exact timeline for domestically-made EUV tools to reach full operational maturity and independence from Western servicing remains uncertain. Additionally, the pace at which China can improve material purity and reduce technological lag is still developing.
As an affiliate, we earn on qualifying purchases.
Next Steps in China’s Semiconductor Development Timeline
Expect continued investment in process optimization and material sourcing, with incremental increases in yield and reliability. The industry will monitor China’s progress in scaling EUV technology and reducing dependence on foreign servicing. Key milestones include achieving stable, high-yield production at sub-10 nanometer nodes, likely around 2030, and further domestic material development to support advanced manufacturing.
As an affiliate, we earn on qualifying purchases.
Key Questions
Why is process learning more important than equipment in chip manufacturing?
Because achieving high yields and reliable production depends on mastering complex, tacit knowledge accumulated through repeated practice, not just having the right machines.
How does China’s progress affect global chip supply chains?
It could reduce dependency on Western equipment and materials, potentially reshaping global supply chains and increasing China's influence in the semiconductor industry.
When might China achieve commercial-scale production at advanced nodes?
Most forecasts suggest around 2030 for sub-10 nanometer nodes, but this depends on overcoming current technological and material challenges.
What are the main obstacles China faces in catching up with Western chipmaking technology?
Key obstacles include achieving high yields, developing domestic high-purity materials, and building mature, self-sustaining manufacturing ecosystems.
